5/8" 2-Flute Solid Carbide Square End Mill, TiB2 - SGS 34683

SGS

5/8" 2-Flute Solid Carbide Square End Mill, TiB2 - SGS 34683

MFR# 34683Series 47E

$330.99List $424.51 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter5/8
Flutes2
MaterialSolid Carbide
CoatingTiB2

Description

The SGS 34683 is a 5/8 2-flute Solid Carbide square end mill. Suited for non-ferrous metal. 3/4 length of cut, 6 overall length. Series 47E.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishTiB2
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachYes
Flute directionRight Hand
Flute typeSpiral
Helix angle35
Length of cut in3/4
Length of cut range0.7000 - 0.8000
Length typeRegular
Mill diameter in5/8
Mill diameter tolerance-0.0001/-0.0004 in
Number of flutes2
Overall length in6
Primary workpiece materialNon-Ferrous Metal
Reach length in3-3/8
Shank diameter in5/8
Shank diameter tolerance+0.00000/-0.00043 in
Shank typeStraight-Cylindrical
Variable helixNo
Variable indexNo
