SPI
Micrometer - SPI CMS220519060
MFR# CMS220519060
$1,580.26List $2,411.14
Save 34%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The SPI CMS220519060 is a carbide micrometer. Meets ASME 89.1.13.
Specifications
Accuracy.0001"
Batteries includedYes
Battery chemistryLithium
Battery size3V; CR2032
CalibratedYes
Data outputYes
Digital counterNo
FeaturesMeasuring contact points are designed to allow measurements near to the bottom of blind holes
Gage depth53.5mm
Maximum extension rod length4in
Maximum measurement0.50
Measuring face materialCarbide
Minimum measurement0
Number of batteries1
Resolution0.000
Rod typeExtension
Rotating spindleYes
Set typeInternal
StandardsASME 89.1.13
Thimble typeRatchet Stop
