Tool-Flo
FLGT4125R Carbide Insert, Grade AC3R, AlTiN - Tool-Flo 6342125RAC3R
MFR# 6342125RAC3RISO/ANSI# FLGT4125RCat# FLGT-4125RSeries Flo-Lock
$40.54List $52.00
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeAC3R
MaterialCarbide
CoatingAlTiN
Description
The Tool-Flo 6342125RAC3R is a FLGT4125R carbide indexable insert, grade AC3R, AlTiN coated. Suited for cast iron, steel.
Specifications
Coating finishAlTiN
Coating processPVD
Corner radius0.0050 - 0.0100
Cutting height0.4530
Cutting width0.125
Full radiusNo
Gage diameter0.3750
Insert handRight Hand
Insert holding methodClamp
Insert materialCarbide
Insert size4125
Insert size code4125
Insert styleFLGT
Insert thickness0.2550
Iso codeFLGT4125R
Manufacturers catalog numberFLGT-4125R
Manufacturer gradeAC3R
Maximum depth of cut0.5500
Maximum depth of cut range0.3000 to 1.0000
Multi use toolNo
Primary workpiece materialCast Iron; Steel
