LNMU06X5ZER-MJ AH3225 Solid Carbide Insert, Grade AH3225, TiAlN - Tungaloy 6782087

Tungaloy

LNMU06X5ZER-MJ AH3225 Solid Carbide Insert, Grade AH3225, TiAlN - Tungaloy 6782087

MFR# 6782087ISO/ANSI# LNMU06X5ZER-MJ AH3225Cat# LNMU06X5ZER-MJSeries LNMU

$23.28List $29.85 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeRectangle
GradeAH3225
MaterialSolid Carbide
CoatingTiAlN

Description

The Tungaloy 6782087 is a LNMU06X5ZER-MJ AH3225 solid carbide indexable insert, grade AH3225, TiAlN coated. Suited for steel, stainless steel.

Specifications

Ansi codeLNMU06X5ZER-MJ AH3225
Chip breakerMJ
Coating finishTiAlN
Coating processPVD
Corner radius0.0787
Cutter series compatibilityEXN06; TXN06
Cutting edge effective length0.2360
Cutting edge styleHoned
Included angle degree90
Inscribed circle0.4720
Inscribed circle range0.4000 to 0.5000
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeRectangle
Insert size06
Insert size code06X5
Insert styleLNMU
Iso codeLNMU06X5ZER-MJ AH3225
Manufacturers catalog numberLNMU06X5ZER-MJ
Manufacturer gradeAH3225
Material applicationSteel; Stainless Steel
Material gradeP20; M20
Maximum depth of cut0.0590
Multi use toolYes
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel
RakeNegative
Relief angle0.00
Single or double sided insertDouble
StandardsISO
Thickness0.2760
Thickness range0.2500 to 0.3500
Width0.4720
