Tungaloy
3QP-WNGA 432 PCBN Insert, Grade BXM20, TiCN - Tungaloy 6804734
MFR# 6804734ISO/ANSI# WNGA080402Series 3QP-WNGA
$96.12List $109.90
Save 12%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeW - Trigon 80-Deg
GradeBXM20
MaterialPCBN
CoatingTiCN
Description
The Tungaloy 6804734 is a 3QP-WNGA 432 pcbn indexable insert, grade BXM20, TiCN coated. Suited for hard material.
Specifications
Ansi insert codeWNGA432
Ansi size code432
Chip breakerFlat Top
Chip breaker operationFinishing
Clearance codeN
Coating finishTiCN
Coating processPVD
Corner radius in1/32
Cutting edge styleHoned
Full radiusNo
Hole diameter0.2030
Included angle80
Industry standard number3QP-WNGA 432
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.6860
Insert materialPCBN
Insert shapeW - Trigon 80-Deg
Insert size code432
Insert styleWNGA
Insert thickness in3/16
Iso code3QP-WNGA 432
Iso insert codeWNGA080402
Iso size code080402
Length range0.6500 - 0.7000
Manufacturers catalog number6804734
Manufacturer gradeBXM20
Material gradeH10
Maximum depth of cut0.0197
Multi use applicationTurning; Facing; Boring
Multi use toolYes
Number of cutting edges3
Primary workpiece materialHard Material
RakeNegative
Rake angle0
Relief angle0
Side clearanceNegative
Single or multi tippedMulti Tipped
StandardsANSI; ISO
Tip length0.0870
Tolerance codeG
Width0.6860
Wiper edgeNo
