CCGW 060204 Polycrystalline Cubic Boron Nitride (PCBN) Insert, Grade BXM20, TiCN - Tungaloy 6805034

Tungaloy

CCGW 060204 Polycrystalline Cubic Boron Nitride (PCBN) Insert, Grade BXM20, TiCN - Tungaloy 6805034

MFR# 6805034ISO/ANSI# 2QP-CCGW 21.51Series 2QP-CCM/GW

$95.34List $109.00 Save 12%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/4
ShapeDiamond 80
GradeBXM20
MaterialPolycrystalline Cubic Boron Nitride (PCBN)
CoatingTiCN

Description

The Tungaloy 6805034 is a CCGW 060204 polycrystalline cubic boron nitride (pcbn) indexable insert, grade BXM20, TiCN coated. Suited for hard material.

Specifications

Chip breakerFlat Top
Clearance codeC
Coating finishTiCN
Coating processPVD
Corner radius in1/64
Cutting edge styleHoned
Full radiusNo
Hole diameter0.1100
Included angle80degree
Industry standard number2QP-CCGW 21.51
Inscribed circle in1/4
Insert handNeutral
Insert holding methodScrew
Insert length0.2560
Insert materialPolycrystalline Cubic Boron Nitride (PCBN)
Insert shapeDiamond 80
Insert size code21.51
Insert styleCCGW
Insert thickness in3/32
Iso codeCCGW 060204
Length range0.0000 - 0.3000
Manufacturers catalog number6805034
Manufacturer gradeBXM20
Maximum depth of cut0.0197
Multi use applicationTurning; Facing; Boring
Multi use toolYes
Number of cutting edges2
Primary workpiece materialHard Material
RakePositive
Rake angle0
Relief angle7
Single or multi tippedMulti Tipped
StandardsANSI; ISO
Tip length0.0910
Tolerance codeG
Width in1/4in
Wiper edgeNo
