4QP-DNGA432 Polycrystalline Cubic Boron Nitride (PCBN) Insert, Grade BXC50, TiN - Tungaloy 6818115

Tungaloy

4QP-DNGA432 Polycrystalline Cubic Boron Nitride (PCBN) Insert, Grade BXC50, TiN - Tungaloy 6818115

MFR# 6818115ISO/ANSI# 4QP-DNGA 432Series 4QP-DNGA

$126.21List $144.30 Save 12%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
ShapeDiamond 55
GradeBXC50
MaterialPolycrystalline Cubic Boron Nitride (PCBN)
CoatingTiN

Description

The Tungaloy 6818115 is a 4QP-DNGA432 polycrystalline cubic boron nitride (pcbn) indexable insert, grade BXC50, TiN coated. Suited for hard material.

Specifications

Chip breakerFlat Top
Clearance codeN
Coating finishTiN
Coating processPVD
Corner radius in1/32
Cutting edge styleHoned
Full radiusNo
Hole diameter0.2030
Included angle55degree
Industry standard number4QP-DNGA 432
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length1.2200
Insert materialPolycrystalline Cubic Boron Nitride (PCBN)
Insert shapeDiamond 55
Insert size code432
Insert styleDNGA
Insert thickness in3/16
Iso code4QP-DNGA432
Length range0.7000 - 10.0000
Manufacturers catalog number6818115
Manufacturer gradeBXC50
Material gradeCoarse Grain
Maximum depth of cut0.0197
Multi use applicationTurning; Facing; Boring; Back Turning; Back Boring
Multi use toolYes
Number of cutting edges4
Primary workpiece materialHard Material
RakeNegative
Rake angle0
Relief angle0
Single or multi tippedMulti Tipped
StandardsANSI; ISO
Tip length0.0830
Tolerance codeG
Width in1/2in
Wiper edgeNo
