4QP-VNGA160404 BXA30 Polycrystalline Cubic Boron Nitride (PCBN) Insert, Grade BXA30, TiAlN - Tungaloy 6853487
MFR# 6853487ISO/ANSI# 4QP-VNGA331Series 4QP-VNGA
$116.67List $133.40
Save 12%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/8
ShapeDiamond 35
GradeBXA30
MaterialPolycrystalline Cubic Boron Nitride (PCBN)
CoatingTiAlN
Description
The Tungaloy 6853487 is a 4QP-VNGA160404 BXA30 polycrystalline cubic boron nitride (pcbn) indexable insert, grade BXA30, TiAlN coated. Suited for hard material.
Specifications
Chip breakerFlat Top
Clearance codeN
Coating finishTiAlN
Coating processPVD
Corner radius in1/64
Cutting edge styleHoned
Full radiusNo
Hole diameter0.1500
Included angle35degree
Industry standard number4QP-VNGA331
Inscribed circle in3/8
Insert handNeutral
Insert holding methodClamp; Pin
Insert length1.3080
Insert materialPolycrystalline Cubic Boron Nitride (PCBN)
Insert shapeDiamond 35
Insert size code331
Insert styleVNGA
Insert thickness in3/16
Iso code4QP-VNGA160404 BXA30
Length range0.7000 - 10.0000
Manufacturers catalog number6853487
Manufacturer gradeBXA30
Material gradeFine Grain
Maximum depth of cut0.0197
Multi use applicationTurning; Facing; Boring; Back Turning; Back Boring
Multi use toolYes
Number of cutting edges4
Primary workpiece materialHard Material
RakeNegative
Rake angle0
Relief angle0
Single or multi tippedMulti Tipped
StandardsANSI; ISO
Tip length0.1220
Tolerance codeG
Width in3/8in
Wiper edgeNo
