Vlier
Spring Plunger - Vlier SS90C
MFR# SS90C
$12.26List $15.39
Save 20%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Vlier SS90C is a aluminum spring plunger.
Specifications
Base thickness in1/4; 0.25in
Base width1.5000; 1.5in
Body length1in; 1.0000
Body materialAluminum
Body width1.5000
Distance between mount hole centers in1-1/8; 1.125in
Distance between mount hole edge0.9380
Final end force25.9lb
Initial end force2lb
Middle end force kg14.00
Mounting slot length in13/64
Mounting slot width0.203in; 0.2030
Stop head height0.875in
Stop head thickness0.2500
Stop head width in1.5in
Stroke length in3/16
Tang profileTangless
