5/8" 2-Flute High Speed Steel Ball End Mill, TiCN - Cleveland C39170

Cleveland

5/8" 2-Flute High Speed Steel Ball End Mill, TiCN - Cleveland C39170

MFR# C39170Series HD-2B

$191.25List $241.02 Save 20%
Stock and current price confirmed on request. Ask us →

We check the supplier's stock and today's price for this item before you order, and reply the same business day.

Check price & lead time first →
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter5/8
Flutes2
MaterialHigh Speed Steel
CoatingTiCN

Description

The Cleveland C39170 is a 5/8 2-flute High Speed Steel ball end mill with a TiCN finish for longer tool life. Suited for cast iron, non-ferrous metal, steel. 1-1/8 length of cut, 5 overall length. Series HD-2B.

Specifications

ChipbreakerNo
Coating finishTiCN
Coolant throughNo
Cutting directionRight Hand
End mill materialHigh Speed Steel
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle30
Length of cut in1-1/8
Length typeRegular
Material removal typeFinishing
Mill diameter in5/8
Number of flutes2
Overall length in5
Primary workpiece materialCast Iron; Non-Ferrous Metal; Steel
Shank diameter in5/8
Single or double endDouble
Variable helixNo
Variable indexNo
