Guhring
1" 6-Flute Solid Carbide Corner Radius & Corner Chamfer End Mill - Guhring 9031510254000
MFR# 9031510254000Series 3151
$625.99List $802.85
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter1
Flutes6
MaterialSolid Carbide
CoatingBright/Uncoated
Description
The Guhring 9031510254000 is a 1 6-flute Solid Carbide (Proprietary) corner radius & corner chamfer end mill. Suited for cast iron, stainless steel, steel. 3 length of cut, 6 overall length. Series 3151.
Specifications
CentercuttingYes
ChipbreakerNo
Coating finishBright/Uncoated
Coolant throughNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle30
Length of cut in3
Length typeExtra Long
Material gradeProprietary
Mill diameter in1
Mill diameter toleranceh10
Number of flutes6
Overall length in6
Primary workpiece materialCast Iron; Stainless Steel; Steel
Shank diameter in1
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexNo
