3/4" 4-Flute Solid Carbide Ball End Mill, AlTiN - Kennametal 6767755

Kennametal

3/4" 4-Flute Solid Carbide Ball End Mill, AlTiN - Kennametal 6767755

MFR# 6767755Cat# H1TE4BN0750L263HASeries H1TEBN..N-L

$784.29List $988.39 Save 20%
Usually ships in 1-3 business days

Ship times are estimates. We confirm availability on every order and email you right away if anything changes.

Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.

Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter3/4
Flutes4
MaterialSolid Carbide
CoatingAlTiN

Description

The Kennametal 6767755 is a 3/4 4-flute Solid Carbide (KCPM15) ball end mill with a AlTiN finish for longer tool life. Suited for steel, stainless steel, cast iron, high-temp alloy, hardened materials. 2-5/8 length of cut, 6 overall length. Series H1TEBN..N-L.

Specifications

Additional informationVersatile Solid Carbide End Mill for Steels, Stainless Steel, Cast Iron, & High Temperature Alloys. Harvi I Te Solid Carbide End Mills Cover a Variety of Operations, Including Dynamic Milling, & Extreme Ramping Operations. Harvi I Te Solid Carbide End M
CentercuttingYes
ChipbreakerNo
Coating finishAlTiN
Coating finish familyAlTiN
Coolant throughNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle36-39
Helix styleVariable
Length of cut in2-5/8
Length typeLong
Manufacturers catalog numberH1TE4BN0750L263HA
Material gradeKCPM15
Material removal typeRoughing & Finishing
Mill diameter in3/4
Neck length0.0000
Nose radius0.3750
Number of flutes4
Overall length in6
Primary workpiece materialSteel; Stainless Steel; Cast Iron; High-Temp Alloy; Hardened Materials
Reach length2.6250
Shank diameter in3/4
Shank typeStraight-Cylindrical
Single or double endSingle
System of measurementFractional Inch
Variable helixYes
Variable indexNo
