M.A. Ford.

0.1968" 4-Flute Solid Carbide Square End Mill, ALtima - M.A. Ford. 15719680A

MFR# 15719680ASeries 157

$114.28List $146.56 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Flutes4

MaterialSolid Carbide

CoatingALtima

Description

The M.A. Ford. 15719680A is a 0.1968 4-flute Solid Carbide (Micrograin) square end mill with a ALtima finish for longer tool life. 0.5906 length of cut. Series 157.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishALtima

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeHelical

Helix angle45

Length of cut0.5906

Length of cut range0.5000 - 0.6000

Material gradeMicrograin

Mill diameter0.1968

Mill diameter tolerance-0.015 to -0.038 mm

Number of flutes4

Overall length (mm)90

Shank diameter0.2362

Shank diameter tolerance-0.0025/-0.0076 mm

Shank typeStraight-Cylindrical

Variable helixNo

Variable indexNo
