1/4" 4-Flute Solid Carbide Ball End Mill, AlTiN - M.A. Ford. 16525000A

MFR# 16525000ASeries 165

$44.33List $56.86 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/4

Flutes4

MaterialSolid Carbide

CoatingAlTiN

Description

The M.A. Ford. 16525000A is a 1/4 4-flute Solid Carbide ball end mill with a AlTiN finish for longer tool life. 1/2 length of cut, 2 overall length. Series 165.

Specifications

ChipbreakerNo

Coating finishAlTiN

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

Helix angle30

Length of cut in1/2

Length typeStub

Mill diameter in1/4

Mill diameter tolerance+0.000 to -0.002 in

Nose radius0.1250

Number of flutes4

Overall length in2

Shank diameter in1/4

Single or double endSingle

Variable helixNo

Variable indexNo
