0.3150" 4-Flute Solid Carbide Ball End Mill, MEGA-64 - Seco 00040369

MFR# 00040369Cat# 160080-MEGA-64Series JH160

$241.51List $309.76 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Flutes4

MaterialSolid Carbide

CoatingMEGA-64

Description

The Seco 00040369 is a 0.3150 4-flute Solid Carbide ball end mill with a MEGA-64 finish for longer tool life. Suited for steel, hard material. Series JH160.

Specifications

ChipbreakerNo

Coating finishMEGA-64

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachYes

Flute directionRight Hand

Flute typeSpiral

Helix angle15

Helix styleLow

Length of cut (mm)6.20

Length typeExtended

Manufacturers catalog number160080-MEGA-64

Material removal typeRoughing & Finishing

Mill diameter0.3150

Mill diameter tolerance+0.02/-0.06 mm

Neck diameter (mm)4.80

Neck length (mm)5.00

Nose radius (mm)4.00

Number of flutes4

Overall length (mm)85.00

Primary workpiece materialSteel; Hard Material

Reach length (mm)11.20

Shank diameter (mm)8.00

Shank diameter toleranceh5

Shank typeStraight-Cylindrical

Single or double endSingle

System of measurementMetric

Tir maximum0.0004

Variable helixNo

Variable indexNo
