Seco

3/8" 3-Flute Solid Carbide Ball End Mill, AlTiN - Seco 17003797

MFR# 17003797Cat# SB335-0.375-D3-B.3-Z3Series SB335

$70.12List $89.93 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/8

Flutes3

MaterialSolid Carbide

CoatingAlTiN

Description

The Seco 17003797 is a 3/8 3-flute Solid Carbide ball end mill with a AlTiN finish for longer tool life. Suited for steel, stainless steel, superalloys & titanium. 1 length of cut, 2-1/2 overall length. Series SB335.

Specifications

ChipbreakerNo

Coating finishAlTiN

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

Helix angle35

Helix styleMedium

Length of cut in1

Length typeStandard

Manufacturers catalog numberSB335-0.375-D3-B.3-Z3

Material removal typeRoughing & Finishing

Mill diameter in3/8

Mill diameter tolerance+0.0000/-0.0020 in

Neck length0.0000

Nose radius0.1875

Number of flutes3

Overall length in2-1/2

Overall length tolerance+0.0600/-0.0600 in

Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium

Reach length1.0000

Shank diameter in3/8

Shank diameter tolerance-0.0001/-0.0004 in

Shank typeWeldon Flat

Single or double endSingle

System of measurementFractional Inch

Tir maximum0.0005

Variable helixNo

Variable indexNo
