Widia

1/2" 4-Flute Solid Carbide Corner Radius & Corner Chamfer End Mill, AlTiN - Widia 5577391

MFR# 5577391Cat# 4S0R13005NWSeries 4S0R

$167.90List $215.33 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/2

Flutes4

MaterialSolid Carbide

CoatingAlTiN

Description

The Widia 5577391 is a 1/2 4-flute Solid Carbide (WP15PE) corner radius & corner chamfer end mill with a AlTiN finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material. 1 length of cut, 3 overall length. Series 4S0R.

Specifications

CentercuttingYes

Chamfer angle45

Chamfer length0.0200

Chamfer width0.0200

ChipbreakerYes

Coating finishAlTiN

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeHelical

Helix styleMedium

Length of cut in1

Length typeRegular

Manufacturers catalog number4S0R13005NW

Material gradeWP15PE

Material removal typeRoughing

Mill diameter in1/2

Number of flutes4

Overall length in3

PitchNormal

Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material

Reach length in1

Secondary workpiece materialStainless Steel; Superalloys & Titanium; Hard Material

Shank diameter in1/2

Shank typeWeldon Flat

Single or double endSingle

Variable helixNo

Variable indexNo
