YG-1

3/8in" 4-Flute Solid Carbide Square End Mill, TiAlN - YG-1 08584TF

MFR# 08584TFSeries E5012

$71.35List $91.50 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/8in

Flutes4

MaterialSolid Carbide

CoatingTiAlN

Description

The YG-1 08584TF is a 3/8in 4-flute Solid Carbide (Micrograin) square end mill with a TiAlN finish for longer tool life. Suited for steel. 1-1/8in length of cut, 3in overall length. Series E5012.

Specifications

CentercuttingNo

ChipbreakerNo

Coating finishTiAlN

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

Helix angle30

Length of cut in1-1/8in

Length of cut range1.0000 - 1.2500

Length typeLong

Material gradeMicrograin

Mill diameter in3/8in

Mill diameter tolerance0.0000 to -0.0012 in

Number of flutes4

Overall length in3in

Primary workpiece materialSteel

Secondary workpiece materialStainless Steel; Cast Iron; Non-Ferrous Metal

Shank diameter in3/8in

Shank diameter tolerance+0.0000 to -0.0005 in

Shank typeStraight-Cylindrical

Variable helixNo

Variable indexNo
