YG-1

1/4" 2-Flute Solid Carbide Ball End Mill, Diamond - YG-1 99625

MFR# 99625Series EI106

$169.31List $217.15 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/4

Flutes2

MaterialSolid Carbide

CoatingDiamond

Description

The YG-1 99625 is a 1/4 2-flute Solid Carbide (Micrograin) ball end mill with a Diamond finish for longer tool life. Suited for aluminum & non-ferrous. 3/4 length of cut, 2-1/2 overall length. Series EI106.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishDiamond

Coating finish familyDiamond

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

Helix angle30

Helix styleMedium

Length of cut in3/4

Length typeStandard

Manufacturers catalog number99625

Material gradeMicrograin

Material removal typeRoughing & Finishing

Mill diameter in1/4

Mill diameter tolerance+0.0000/-0.0012 in

Neck length0.0000

Nose radius0.1250

Number of flutes2

Overall length in2-1/2

Primary workpiece materialAluminum & Non-Ferrous

Reach length0.7500

Secondary workpiece materialAluminum & Non-Ferrous

Shank diameter in1/4

Shank diameter tolerance+0.0000/-0.0003 in

Shank typeStraight-Cylindrical

Single or double endSingle

System of measurementFractional Inch

Variable helixNo

Variable indexNo
