APT
Indexable Milling Cutters - APT SM2475R-4
MFR# SM2475R-4Series SM
$357.65List $450.73
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Cutter dia.2
Description
The APT SM2475R-4 indexable milling cutters. Suited for universal. Series SM.
Specifications
Compatible insert size code4
Compatible insert styleCTA
Complete insert compatibilityCTA-4
Connection typeShank
Coolant throughNo
Cutter body width0.4500
Cutter diameter in2
Cutting directionRight Hand
Cutting radius frac in1
Cutting width in49/64
Insert holding methodClamp
Insert inscribed circle (mm)0.46
Lead angle87
Manufacturers catalog numberSM2475R-4
Maximum cutting width0.7650
Maximum depth of cut0.5620
Minimum cutting width0.4850
Number of cutter inserts4
Number of teeth4
Overall height3.0000
Primary workpiece materialUniversal
RadiusNo
RakePositive
Shank diameter in3/4
Shank length2.5500
Toolholder styleSM
Tool applicationMilling; Slotting
Tool materialSteel
Tool performanceGeneral Purpose
Tooth typeStaggered
Wedge numberW-4
Weldon flatYes
