Chicago-Latrobe
5/32" Cobalt Drill Bit, Gold Finish, 135° point - Chicago-Latrobe 47710
MFR# 47710
$2.76List $3.54
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Drill size5/32
Description
The Chicago-Latrobe 47710 is a 5/32" Cobalt drill bit with a Gold Finish finish, 135° point.
Specifications
Coolant throughNo
Cutting directionRight Hand
Drill bit diameter tolerance+0.0000 to -0.0007 in
Drill bit finish coatingGold Finish
Drill bit gradeHeavy Duty
Drill bit materialCobalt
Drill bit size in5/32
Drill bit size range0.1500 - 0.2000
Drill point angle degrees135
Flute length2.0000
Flute typeSpiral
Overall length3.1250
Point typeSplit
Shank diameter in5/32
Shank length1.1252
Shank typeStraight-Cylindrical
Specification designationNAS
Specification numberNAS 907-B
Spiral typeRegular
Web configurationTapered
Web thinningWeb-Thinned
