Chicago-Latrobe
1/2" Cobalt Drill Bit, Gold, 135° point - Chicago-Latrobe 47732
MFR# 47732Series 550ASP
$18.90List $24.25
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Drill size1/2
Flutes2
Description
The Chicago-Latrobe 47732 is a 1/2" Cobalt drill bit with a Gold finish, 135° point. Suited for titanium. Series 550ASP.
Specifications
Coolant throughNo
Cutting directionRight Hand
Drill bit diameter tolerance+0.0000 to -0.0010 in
Drill bit finish coatingGold
Drill bit gradeHeavy Duty
Drill bit materialCobalt
Drill bit size in1/2
Drill bit size range0.5000 - 0.6500
Drill point angle degrees135
Flute length4.5000
Flute typeSpiral
Number of flutes2
Overall length6.0000
Point typeSplit
Primary workpiece materialTitanium
Shank diameter in1/2
Shank length1.5000
Shank typeStraight-Cylindrical
Specification designationNAS
Specification numberNAS 907-B
Spiral typeRegular
StandardsNAS 907 Type B
Tool performanceHigh Performance
Web configurationTapered
Web thinningWeb-Thinned
Can't find your exact tool?Send us a part number — we'll cross-reference it.
Dull tools?Regrinding extends tool life and saves cost.
Alternate & equivalent tools
Matched on diameter, flute count, and material. Need a specific brand or coating? Cross-reference this tool.
Spec-matched alternates load as the catalog fills in. Meanwhile, browse the End Mills collection and filter by diameter, flutes & length of cut.
