Cle-Force
27/64" High Speed Steel Drill Bit, 118° point - Cle-Force C68137
MFR# C68137Series 1601
$5.72List $7.21
Save 20%
Stock and current price confirmed on request. Ask us →
We check the supplier's stock and today's price for this item before you order, and reply the same business day.
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Drill size27/64
Flutes2
Description
The Cle-Force C68137 is a 27/64" High Speed Steel drill bit, 118° point. Suited for aluminum. 3-15/16 flute length, 5-3/8 overall length. Series 1601.
Specifications
Coolant throughNo
Cutting directionRight Hand
Drill bit diameter tolerance+0.0000 to -0.0010 in
Drill bit finish coatingBright/Uncoated
Drill bit gradeGeneral Purpose
Drill bit materialHigh Speed Steel
Drill bit size in27/64
Drill bit size range0.4000 - 0.5000
Drill point angle degrees118
Flute length in3-15/16
Flute typeSpiral
Number of flutes2
Overall length in5-3/8
Point typeStandard
Primary workpiece materialAluminum
Shank diameter in27/64
Shank length1.4378
Shank typeStraight-Cylindrical
Spiral typeRegular
StandardsASME B94.11M; DIN 338
Tool performanceGeneral Purpose
Web configurationTapered
Web thinningWeb-Thinned
