Cleveland
#44 Cobalt Drill Bit, Black Oxide, 135° point - Cleveland C16767
MFR# C16767Series 2575
$24.66List $31.07
Save 20%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
CoatingBlack Oxide
Description
The Cleveland C16767 is a #44 Cobalt drill bit with a Black Oxide finish, 135° point. 2-1/4 flute length. Series 2575.
Specifications
Coating finishBlack Oxide
Coolant throughNo
Cutting directionRight Hand
Drill bit diameter tolerance+0.0000 to -0.0005 in
Drill bit gradeHeavy-Duty
Drill bit size0.0860
Drill bit size wire#44
Drill point angle degrees135
Flute length in2-1/4
Flute typeParabolic
Material applicationAluminum; Brass; Carbon Steel; Cast Iron; Nickel Alloy; Plastic; Stainless Steel; Tool Steel
Material gradeM42
Overall length4-1/4in
Point typeSplit
Shank diameter0.0860
Shank length2.0000in
Shank typeStraight-Cylindrical
Specification numberDIN 338
StandardsASME B94.11M; DIN 340
Threaded shankNo
Tool materialCobalt
Web configurationTapered
Web thinningWeb-Thinned
