Cleveland
5/16" 4-Flute High Speed Steel Square End Mill, TiCN - Cleveland C33461
MFR# C33461Series HG-4C
$54.90List $70.40
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter5/16
Flutes4
MaterialHigh Speed Steel
CoatingTiCN
Description
The Cleveland C33461 is a 5/16 4-flute High Speed Steel square end mill with a TiCN finish for longer tool life. Suited for cast iron, non-ferrous metal, steel. 2 length of cut, 3-1/4 overall length. Series HG-4C.
Specifications
CentercuttingYes
ChipbreakerNo
Coating finishTiCN
Cutting directionRight Hand
End mill materialHigh Speed Steel
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle30
Length of cut in2
Length of cut range2.0000+
Length typeExtra Long
Mill diameter in5/16
Number of flutes4
Overall length in3-1/4
Primary workpiece materialCast Iron; Non-Ferrous Metal; Steel
Shank diameter in3/8
Shank typeStraight-Cylindrical; Weldon Flat
Variable helixNo
Variable indexNo
