Cleveland
9/16" Carbide-Tipped Drill Bit, Gold, 118° point - Cleveland C49145
MFR# C49145Series 2745
$118.16List $151.55
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Drill size9/16
CoatingGold
Description
The Cleveland C49145 is a 9/16" Carbide-Tipped drill bit with a Gold finish, 118° point. Series 2745.
Specifications
Coating finishGold
Coolant throughNo
Cutting directionRight Hand
Drill bit diameter tolerance+0.0000 to -0.0012 in
Drill bit size in9/16
Drill point angle degrees118
Flute length4.8750
Flute typeSpiral
Overall length8-1/4
Point typeStandard
Shank diameter in9/16
Shank length3.3748
Shank typeTanged
Spiral typeRegular
Tool materialCarbide-Tipped
Web configurationTapered
Web thinningWeb-Thinned
