Dayton Lamina
Aluminum Bronze Die Bushing - Dayton Lamina S875-35G
MFR# S875-35G
$130.31List $163.58
Save 20%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Dayton Lamina S875-35G is a aluminum bronze die bushing.
Specifications
Attachment methodPress-Fit
Bin1.43
Body typeShoulder
Bottom outside diameter1.2505
Bushing typeFriction
Collar height frac in3/16
Collar outside diameter1.4300
D in0.8755
Inside diameter in7/8
Length above collar in4-3/16
Lubrication typeSelf-Lubricating
MaterialAluminum Bronze
Tolerance+0.0000in; -0.0600in
Top outside diameter1.2505
