De-Sta-Co
Toggle Clamp - De-Sta-Co 630-M
MFR# 630-M
$74.79
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The De-Sta-Co 630-M is a carbon steel toggle clamp.
Specifications
Base length5.0300
Base styleFlanged
Base width in2.2500
Clamp materialCarbon Steel
F 6 31 (Pushing)
Handle colorRed
Handle styleStraight
Length distance between mount holes in1.3800
Load capacity11120.6N; 2500lb
Load capacity n11120.60
MaterialCarbon Steel
Maximum mechanical advantage23:1 (Pulling)
Mounting hole diameter (mm)8.64
Number of mounting holes6
Overall height3.0500
Overall length7.0600
Plunger centerline height0.8100
Plunger diameter0.6200
Plunger shapeRound
Plunger thread sizeM10
Plunger thread styleInternal
Plunger travel2.0000
Width distance between mount holes1.6300
