De-Sta-Co
Toggle Clamp - De-Sta-Co 650-M
MFR# 650-M
$263.93
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The De-Sta-Co 650-M is a carbon steel toggle clamp.
Specifications
Base length7.8100
Base styleFlanged
Base width in3.2500
Clamp materialCarbon Steel
Handle colorRed
Handle styleStraight
Length distance between mount holes in2.7500
Load capacity71171.5N; 16000lb
Load capacity n71171.50
MaterialCarbon Steel
Mounting hole diameter (mm)10.41
Number of mounting holes4
Overall height4.8400
Overall length11.1600
Plunger centerline height2.2500
Plunger diameter0.9900
Plunger shapeRound
Plunger thread sizeM16
Plunger thread styleInternal
Plunger travel3.0000
Width distance between mount holes2.2500
