11/64" HSS Screw Machine Drill Bit, TiN, 130° point - Dormer Pramet 5970200

Dormer Pramet

11/64" HSS Screw Machine Drill Bit, TiN, 130° point - Dormer Pramet 5970200

MFR# 5970200Series A520

$16.20List $20.78 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Drill size11/64
Flutes2
CoatingTiN

Description

The Dormer Pramet 5970200 is a 11/64" HSS Screw Machine drill bit with a TiN finish, 130° point. Suited for steel, stainless steel, cast iron, aluminum & non-ferrous, high-temp alloy. Series A520.

Specifications

Coating finishTiN
Coolant throughNo
Cutting directionRight Hand
Drill bit gradeHeavy Duty
Drill bit size in11/64
Drill bit size range0.1500 to 0.2000
Drill length typeScrew Machine
Drill point angle130
Flute by diameter ratio2.5xD
Flute length (mm)24.00
Flute typeRegular Spiral
Number of flutes2
Overall length2.2835
Point typeWeb-Thinned
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Aluminum & Non-Ferrous; High-Temp Alloy
Shank diameter0.1719
Shank length1.3386
Shank typeStraight
Specification designationDIN
Specification numberDIN 1897
Spiral typeRegular
StandardsDIN 1897
Tool materialHSS
Tool performanceHigh Performance
Web configurationParallel
Web thinningWeb-Thinned
Can't find your exact tool?Send us a part number — we'll cross-reference it. Dull tools?Regrinding extends tool life and saves cost.
