Emuge
#10-24 UNC Tap, TiCN - Emuge BU539300.5007
MFR# BU539300.5007Series Enorm
$32.08List $36.05
Save 11%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
Supplier prices are confirmed before checkout. If one has changed since this page was updated, we show you the new price before you pay.
Request a quote- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes3
Thread size#10-24
CoatingTiCN
Description
The Emuge BU539300.5007 is a #10-24 UNC tap with a TiCN finish. 3 flutes.
Specifications
ApplicationBlind Hole Threading
ChamferBottoming
Class of fit2B/3B
Coating finishTiCN
Coolant throughNo
Flute directionRight Hand
Flute styleSpiral
Helix angle35
Material applicationCast Iron; Non-Ferrous Metal; Stainless Steel; Steel
Number of flutes3
Overall length2.7560
OversizeNo
Shank diameter0.2200
Square size0.1520
Tapping depth0.9840
Threads per inch24
Thread directionRight Hand
Thread length0.5910
Thread size in#10-24
Thread standardUNC
