Emuge
Solid Carbide Drill Bit, TiAIN, 140° point - Emuge TE213324.0255
MFR# TE213324.0255Series EF-Drill
$241.04List $298.33
Save 19%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes2
CoatingTiAIN
Description
The Emuge TE213324.0255 is a Solid Carbide drill bit with a TiAIN finish, 140° point. Series EF-Drill.
Specifications
Coating finishTiAIN
Coolant throughYes
Cutting directionRight Hand
Double marginYes
Drill bit materialSolid Carbide
Drill point angle degrees140
Flute by diameter ratio6xD
Flute length (mm)22.50
Flute typeRegular Spiral
Number of flats2
Number of flutes2
Overall length (mm)65.00
Point typeStandard
Shank diameter (mm)4.00
Shank length (mm)42.50
Shank typeRound with Flats
Spiral typeRegular
Can't find your exact tool?Send us a part number — we'll cross-reference it.
Dull tools?Regrinding extends tool life and saves cost.
Alternate & equivalent tools
Matched on diameter, flute count, and material. Need a specific brand or coating? Cross-reference this tool.
Spec-matched alternates load as the catalog fills in. Meanwhile, browse the End Mills collection and filter by diameter, flutes & length of cut.
