Guhring
#8-36 UNF Cobalt Tap - Guhring 9039320041660
MFR# 9039320041660Series 3932
$23.00List $29.49
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes2
Thread size#8-36
Description
The Guhring 9039320041660 is a #8-36 UNF Cobalt tap. 2 flutes.
Specifications
ApplicationBlind Hole Threading
ChamferModified Bottoming
Class of fit2B
Coolant throughNo
Flute directionRight Hand
Flute styleFast
Helix angle45
MaterialCobalt
Material applicationAluminum; Aluminum Alloy
Neck length0.8270
Number of flutes2
Overall length in2-1/8
OversizeNo
Shank diameter0.1680
Square size0.1310
Threads per inch36
Thread directionRight Hand
Thread limitH2; H3
Thread size in#8-36
Thread standardUNF
