Guhring
7/16-20 UNF Cobalt Tap - Guhring 9039320111130
MFR# 9039320111130Series 3932
$41.60List $53.35
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes2
Thread size7/16-20
Description
The Guhring 9039320111130 is a 7/16-20 UNF Cobalt tap. 2 flutes.
Specifications
ApplicationBlind Hole Threading
ChamferModified Bottoming
Class of fit2B
Coolant throughNo
Flute directionRight Hand
Flute styleFast
Helix angle45
MaterialCobalt
Material applicationAluminum; Aluminum Alloy
Number of flutes2
Overall length in3-5/32
OversizeNo
Shank diameter0.3230
Square size0.2420
Threads per inch20
Thread directionRight Hand
Thread limitH4; H5
Thread size in7/16-20
Thread standardUNF
