Guhring
M12x1.75 Metric High-Speed Steel-E-CO Tap, TiCN - Guhring 9039420120000
MFR# 9039420120000Series 3942
$71.82List $92.12
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
CoatingTiCN
Description
The Guhring 9039420120000 is a Metric High-Speed Steel-E-CO tap with a TiCN finish.
Specifications
ApplicationBlind Hole Threading; Through-Hole Threading
ChamferModified Bottoming
Chamfered threads2-3P
Class of fit6HX
Coating finishTiCN
Coolant throughNo
Flute by diameter ratio3xD
MaterialHigh-Speed Steel-E-CO
Material applicationSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal
Material application codeP; M; K; N
Oil grooves5
Overall length3.3820
Shank diameter0.3670
Square size0.2756
Tapping depth1.4567
Thread directionRight Hand
Thread length0.7874
Thread limitD11; D12
Thread size (mm)M12x1.75
Thread standardMetric
