5/16in" 3-Flute Solid Carbide Corner Radius End Mill - GWS 125654

GWS

5/16in" 3-Flute Solid Carbide Corner Radius End Mill - GWS 125654

MFR# 125654Series 1020

$72.15List $92.54 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter5/16in
Flutes3
MaterialSolid Carbide
CoatingBright/Uncoated

Description

The GWS 125654 is a 5/16in 3-flute Solid Carbide (Submicron) corner radius end mill. Suited for non-ferrous metal. 1-1/8in length of cut, 3in overall length. Series 1020.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishBright/Uncoated
Coolant throughNo
Corner radius0.0500
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
For use withEnd Mill Toolholders
Helix styleHigh
Length of cut in1-1/8in
Length typeLong
Material applicationNon-Ferrous Metal
Material gradeSubmicron
Material removal typeRoughing
Mill diameter in5/16in
Number of flutes3
Overall length in3in
PitchCoarse
Primary workpiece materialNon-Ferrous Metal
Shank diameter in5/16in
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixNo
Variable indexNo
