Harvey Tool
Triangle 3/8" IC Solid Carbide Insert - Harvey Tool 60038
MFR# 60038Cat# TPET-321-AL
$21.39List $24.97
Save 14%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/8
ShapeTriangle
MaterialSolid Carbide
Description
The Harvey Tool 60038 is a solid carbide indexable insert. Suited for non-ferrous metal.
Specifications
Ansi codeTPET-321-AL
Chip breakerAL
Coating processUncoated
Corner radius in1/64
Cutter series compatibility81250; 81260
Cutting edge styleSingle Sided
Included angle degree60
Inscribed circle in3/8
Inscribed circle range0.3500 to 0.4000
Insert handNeutral
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeTriangle
Insert size3
Insert size code321
Insert styleTPET
Length0.6500
Length range0.6500 to 0.7000
Manufacturers catalog numberTPET-321-AL
Material applicationNon-Ferrous Metal
Maximum depth of cut0.1250
Multi use toolNo
Number of cutting edges3
Primary workpiece materialNon-Ferrous Metal
RakePositive
Relief angle11.00
Single or double sided insertSingle
StandardsANSI
Thickness in1/8
Thickness range0.1250 to 0.1500
Width0.6500
