0.1969" 4-Flute Solid Carbide Corner Radius End Mill, AlTiN - Harvey Tool 979364-C6
MFR# 979364-C6Series Variable Helix End Mills for High Temp Alloys - Corner Radius; Material Specific End Mills
$54.74List $63.91
Save 14%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes4
MaterialSolid Carbide
CoatingAlTiN
Description
The Harvey Tool 979364-C6 is a 0.1969 4-flute Solid Carbide corner radius end mill with a AlTiN finish for longer tool life. Suited for steel, stainless steel, cast iron, hard material. Series Variable Helix End Mills for High Temp Alloys - Corner Radius; Material Specific End Mills.
Specifications
CentercuttingYes
ChipbreakerNo
Coating finishAlTiN
Coolant throughNo
Corner radius (mm)0.40
Corner radius tolerance0.025 to -0.025 mm
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
For use withHigh Precision Toolholders
Length of cut0.5906
Length typeRegular
Material applicationCast Iron; Steel; Stainless Steel; Hard Alloy
Material removal typeRoughing & Finishing
Mill diameter0.1969
Mill diameter tolerance0.00/-0.04 mm
Number of flutes4
Overall length (mm)63.00
Overall length tolerance0.75/-0.00 mm
PitchNormal
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Hard Material
Shank diameter (mm)6
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Variable helixYes
Variable indexNo
