Helical Solutions

1/4" 5-Flute Solid Carbide Corner Radius End Mill, APLUS - Helical Solutions 35122

MFR# 35122Series HEV-RN-5

$72.93List $85.14 Save 14%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/4

Flutes5

MaterialSolid Carbide

CoatingAPLUS

Description

The Helical Solutions 35122 is a 1/4 5-flute Solid Carbide corner radius end mill with a APLUS finish for longer tool life. Suited for steel, cast iron. 3/8 length of cut, 4 overall length. Series HEV-RN-5.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishAPLUS

Coolant throughNo

Corner radius0.0200

Corner radius tolerance-0.0020 to 0.0020 in

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachYes

Flute directionRight Hand

Flute typeHelical

For use withHigh Precision Toolholder

Length of cut in3/8

Length typeRegular

Material applicationLow-Alloy Steel; Medium Alloy Steel; Tool Steel; Cast Iron

Material removal typeRoughing & Finishing

Mill diameter in1/4

Mill diameter tolerance-0.0020 to 0.0000 in

Neck diameter0.2370

Number of flutes5

Overall length in4

Overall length tolerance-0.0620 to 0.0620 in

PitchVariable

Primary workpiece materialSteel; Cast Iron

Reach length in1-1/8

Secondary workpiece materialStainless Steel; Superalloys & Titanium

Shank diameter in1/4

Shank diameter toleranceh6

Shank typeStraight-Cylindrical

Single or double endSingle

Tir maximum0.0005

Variable helixNo

Variable indexYes
