1/2" 8-Flute Solid Carbide Corner Radius End Mill, APLUS - Helical Solutions 36076

Helical Solutions

1/2" 8-Flute Solid Carbide Corner Radius End Mill, APLUS - Helical Solutions 36076

MFR# 36076Series HXF

$123.12List $141.24 Save 12%
Usually ships in 1-3 business days

Ship times are estimates. We confirm availability on every order and email you right away if anything changes.

⚡ Need it urgently? Confirm stock & ship time →

Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/2
Flutes8
MaterialSolid Carbide
CoatingAPLUS

Description

The Helical Solutions 36076 is a 1/2 8-flute Solid Carbide corner radius end mill with a APLUS finish for longer tool life. Suited for superalloys & titanium. 5/8 length of cut, 2-1/2 overall length. Series HXF.

Specifications

CentercuttingNo
ChipbreakerNo
Coating finishAPLUS
Coolant throughNo
Corner radius0.0300
Corner radius tolerance-0.0020 to 0.0020 in
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
For use withHigh Precision Toolholders
Length of cut in5/8
Length typeStub
Material applicationTitanium; Titanium Alloy
Material removal typeFinishing
Mill diameter in1/2
Mill diameter tolerance-0.0020/0.0000 in
Number of flutes8
Overall length in2-1/2
Overall length tolerance-0.0620/0.0620 in
PitchSuper Close
Primary workpiece materialSuperalloys & Titanium
Shank diameter in1/2
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Tir maximum0.0005
Variable helixNo
Variable indexNo
