1/2" 8-Flute Solid Carbide Corner Radius End Mill, APLUS - Helical Solutions 36106

MFR# 36106Series HXF

$132.19List $154.33 Save 14%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/2

Flutes8

MaterialSolid Carbide

CoatingAPLUS

Description

The Helical Solutions 36106 is a 1/2 8-flute Solid Carbide corner radius end mill with a APLUS finish for longer tool life. Suited for superalloys & titanium. 1-1/4 length of cut, 3 overall length. Series HXF.

Specifications

CentercuttingNo

ChipbreakerNo

Coating finishAPLUS

Coolant throughNo

Corner radius0.0300

Corner radius tolerance-0.0020 to 0.0020 in

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

For use withHigh Precision Toolholders

Length of cut in1-1/4

Length typeRegular

Material applicationTitanium; Titanium Alloy

Material removal typeFinishing

Mill diameter in1/2

Mill diameter tolerance-0.0020/0.0000 in

Number of flutes8

Overall length in3

Overall length tolerance-0.0620/0.0620 in

PitchSuper Close

Primary workpiece materialSuperalloys & Titanium

Shank diameter in1/2

Shank diameter toleranceh6

Shank typeStraight-Cylindrical

Single or double endSingle

Tir maximum0.0005

Variable helixNo

Variable indexNo
