Helical Solutions

1" 4-Flute Solid Carbide Corner Radius End Mill, APLUS - Helical Solutions 53396

MFR# 53396Series HSV-RN-4

$369.51List $400.25 Save 7%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1

Flutes4

MaterialSolid Carbide

CoatingAPLUS

Description

The Helical Solutions 53396 is a 1 4-flute Solid Carbide corner radius end mill with a APLUS finish for longer tool life. Suited for steel, cast iron. 1-1/4 length of cut, 4 overall length. Series HSV-RN-4.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishAPLUS

Coolant throughNo

Corner radius0.2500

Corner radius tolerance-0.0020 to 0.0020 in

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachYes

Flute directionRight Hand

Flute typeSpiral

For use withHigh Precision Toolholders

Length of cut in1-1/4

Length typeStub

Material applicationLow-Alloy Steel; Medium Alloy Steel; Tool Steel; Cast Iron; Titanium

Material removal typeRoughing & Finishing

Mill diameter in1

Mill diameter tolerance-0.0020/0.0000 in

Neck diameter0.9500

Number of flutes4

Overall length in4

Overall length tolerance-0.0620/0.0620 in

PitchVariable

Primary workpiece materialSteel; Cast Iron

Reach length in2-1/4

Shank diameter in1

Shank diameter toleranceh6

Shank typeStraight-Cylindrical

Single or double endSingle

Tir maximum0.0005

Variable helixNo

Variable indexYes
