1/2" 6-Flute Solid Carbide Corner Radius End Mill, APLUS - Helical Solutions 59323

Helical Solutions

1/2" 6-Flute Solid Carbide Corner Radius End Mill, APLUS - Helical Solutions 59323

MFR# 59323Series HEV-6

$125.60List $146.63 Save 14%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/2
Flutes6
MaterialSolid Carbide
CoatingAPLUS

Description

The Helical Solutions 59323 is a 1/2 6-flute Solid Carbide corner radius end mill with a APLUS finish for longer tool life. Suited for steel, cast iron. 5/8 length of cut, 2-1/2 overall length. Series HEV-6.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishAPLUS
Coolant throughNo
Corner radius0.1250
Corner radius tolerance-0.0020 to 0.0020 in
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
For use withHigh Precision Toolholders
Length of cut in5/8
Length typeStub
Material applicationLow-Alloy Steel; Medium Alloy Steel; Tool Steel; Cast Iron; Titanium
Material removal typeRoughing & Finishing
Mill diameter in1/2
Mill diameter tolerance-0.0020/0.0000 in
Number of flutes6
Overall length in2-1/2
Overall length tolerance-0.0620/0.0620 in
PitchVariable
Primary workpiece materialSteel; Cast Iron
Secondary workpiece materialStainless Steel; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
Shank diameter in1/2
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Tir maximum0.0005
Variable helixNo
Variable indexYes
