Helical Solutions

3/4" 6-Flute Solid Carbide Corner Radius End Mill, APLUS - Helical Solutions 82089

MFR# 82089Series HVTI-6

$274.22List $297.02 Save 7%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/4

Flutes6

MaterialSolid Carbide

CoatingAPLUS

Description

The Helical Solutions 82089 is a 3/4 6-flute Solid Carbide corner radius end mill with a APLUS finish for longer tool life. Suited for superalloys & titanium. 1-5/8 length of cut, 4 overall length. Series HVTI-6.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishAPLUS

Coolant throughNo

Corner radius0.0600

Corner radius tolerance-0.0020 to 0.0020 in

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

For use withHigh Precision Toolholders

Length of cut in1-5/8

Length typeRegular

Material applicationTitanium; Titanium Alloy

Material removal typeRoughing & Finishing

Mill diameter in3/4

Mill diameter tolerance-0.0020/0.0000 in

Number of flutes6

Overall length in4

Overall length tolerance-0.0620/0.0620 in

PitchVariable

Primary workpiece materialSuperalloys & Titanium

Shank diameter in3/4

Shank diameter toleranceh6

Shank typeStraight-Cylindrical

Single or double endSingle

Tir maximum0.0005

Variable helixNo

Variable indexYes
