Helical Solutions

3/4" 6-Flute Solid Carbide Corner Radius End Mill, APLUS - Helical Solutions 82090

MFR# 82090Series HVTI-6

$313.39List $339.46 Save 7%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/4

Flutes6

MaterialSolid Carbide

CoatingAPLUS

Description

The Helical Solutions 82090 is a 3/4 6-flute Solid Carbide corner radius end mill with a APLUS finish for longer tool life. Suited for superalloys & titanium. 2-1/4 length of cut, 5 overall length. Series HVTI-6.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishAPLUS

Coolant throughNo

Corner radius0.0600

Corner radius tolerance-0.0020 to 0.0020 in

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

For use withHigh Precision Toolholders

Length of cut in2-1/4

Length typeStandard

Material applicationTitanium; Titanium Alloy

Material removal typeRoughing & Finishing

Mill diameter in3/4

Mill diameter tolerance-0.0020/0.0000 in

Number of flutes6

Overall length in5

Overall length tolerance-0.0620/0.0620 in

PitchVariable

Primary workpiece materialSuperalloys & Titanium

Shank diameter in3/4

Shank diameter toleranceh6

Shank typeStraight-Cylindrical

Single or double endSingle

Tir maximum0.0005

Variable helixNo

Variable indexYes
