1/2" 4-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 82319

Helical Solutions

1/2" 4-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 82319

MFR# 82319Series HSV-4

$137.02List $157.19 Save 12%
Usually ships in 1-3 business days

Ship times are estimates. We confirm availability on every order and email you right away if anything changes.

⚡ Need it urgently? Confirm stock & ship time →

Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/2
Flutes4
MaterialSolid Carbide
CoatingTplus

Description

The Helical Solutions 82319 is a 1/2 4-flute Solid Carbide corner radius end mill with a Tplus finish for longer tool life. Suited for stainless steel, superalloys & titanium, hard material. 5/8 length of cut, 2-1/2 overall length. Series HSV-4.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishTplus
Coolant throughNo
Corner radius0.0300
Corner radius tolerance-0.0020 to 0.0020 in
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
For use withHigh Precision Toolholders
Length of cut in5/8
Length typeStub
Material applicationStainless Steel; High-Temperature Alloy; Hardened Steel
Material removal typeRoughing & Finishing
Mill diameter in1/2
Mill diameter tolerance-0.0020/0.0000 in
Number of flutes4
Overall length in2-1/2
Overall length tolerance-0.0620/0.0620 in
PitchVariable
Primary workpiece materialStainless Steel; Superalloys & Titanium; Hard Material
Secondary workpiece materialSteel; Cast Iron
Shank diameter in1/2
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Tir maximum0.0005
Variable helixNo
Variable indexYes
