1/4in" 5-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 82983

Helical Solutions

1/4in" 5-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 82983

MFR# 82983Series HEV-5

$65.20List $76.12 Save 14%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/4in
Flutes5
MaterialSolid Carbide
CoatingTplus

Description

The Helical Solutions 82983 is a 1/4in 5-flute Solid Carbide corner radius end mill with a Tplus finish for longer tool life. Suited for stainless steel, superalloys & titanium. 3/4in length of cut, 2-1/2in overall length. Series HEV-5.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishTplus
Coolant throughNo
Corner radius0.0150
Corner radius tolerance-0.0020 to 0.0020 in
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
For use withHigh Precision Toolholders
Length of cut in3/4in
Length typeRegular
Material applicationStainless Steel; Superalloys & Titanium
Material removal typeRoughing & Finishing
Mill diameter in1/4in
Mill diameter tolerance-0.0020/0.0000 in
Number of flutes5
Overall length in2-1/2in
Overall length tolerance-0.0620/0.0620 in
PitchVariable
Primary workpiece materialStainless Steel; Superalloys & Titanium
Secondary workpiece materialNon-Ferrous Metal; Hard Material
Shank diameter in1/4in
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Tir maximum0.0005
Variable helixNo
Variable indexYes
