Helical Solutions

3/8" 7-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 83519

MFR# 83519Series HXF

$93.09List $108.68 Save 14%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/8

Flutes7

MaterialSolid Carbide

CoatingTplus

Description

The Helical Solutions 83519 is a 3/8 7-flute Solid Carbide corner radius end mill with a Tplus finish for longer tool life. Suited for stainless steel, superalloys & titanium, hard material. 1-1/4 length of cut, 3 overall length. Series HXF.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishTplus

Coolant throughNo

Corner radius0.0200

Corner radius tolerance-0.0020 to 0.0020 in

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

For use withHigh Precision Toolholders

Length of cut in1-1/4

Length typeStandard

Material applicationStainless Steel; High-Temperature Alloy; Hardened Steel

Material removal typeFinishing

Mill diameter in3/8

Mill diameter tolerance-0.0020/0.0000 in

Number of flutes7

Overall length in3

Overall length tolerance-0.0620/0.0620 in

PitchSuper Close

Primary workpiece materialStainless Steel; Superalloys & Titanium; Hard Material

Shank diameter in3/8

Shank diameter toleranceh6

Shank typeStraight-Cylindrical

Single or double endSingle

Tir maximum0.0005

Variable helixNo

Variable indexNo
