Helical Solutions
3/32" 5-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 84065
MFR# 84065Series HSM-5
$56.86List $65.23
Save 12%
Usually ships in 1-3 business days
Ship times are estimates. We confirm availability on every order and email you right away if anything changes.
⚡ Need it urgently? Confirm stock & ship time →
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter3/32
Flutes5
MaterialSolid Carbide
CoatingTplus
Description
The Helical Solutions 84065 is a 3/32 5-flute Solid Carbide corner radius end mill with a Tplus finish for longer tool life. Suited for stainless steel, superalloys & titanium, hard material. 9/32 length of cut, 2-1/2 overall length. Series HSM-5.
Specifications
CentercuttingYes
ChipbreakerNo
Coating finishTplus
Coolant throughNo
Corner radius0.0100
Corner radius tolerance-0.0020 to 0.0020 in
Cutting directionRight Hand
End mill materialSolid Carbide
End typeCorner Radius
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
For use withHigh Precision Toolholders
Length of cut in9/32
Length typeStandard
Material applicationStainless Steel; High-Temperature Alloy; Hardened Steel
Material removal typeFinishing
Mill diameter in3/32
Mill diameter tolerance-0.0020/0.0000 in
Number of flutes5
Overall length in2-1/2
Overall length tolerance-0.0620/0.0620 in
PitchVariable
Primary workpiece materialStainless Steel; Superalloys & Titanium; Hard Material
Secondary workpiece materialSteel; Cast Iron
Shank diameter in1/4
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Single or double endSingle
Tir maximum0.0005
Variable helixNo
Variable indexYes
