Helical Solutions

3/32" 5-Flute Solid Carbide Corner Radius End Mill, Tplus - Helical Solutions 84066

MFR# 84066Series HSM-5

$58.14List $67.87 Save 14%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter3/32

Flutes5

MaterialSolid Carbide

CoatingTplus

Description

The Helical Solutions 84066 is a 3/32 5-flute Solid Carbide corner radius end mill with a Tplus finish for longer tool life. Suited for stainless steel, superalloys & titanium, hard material. 1/2 length of cut, 2-1/2 overall length. Series HSM-5.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishTplus

Coolant throughNo

Corner radius0.0100

Corner radius tolerance-0.0020 to 0.0020 in

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

For use withHigh Precision Toolholders

Length of cut in1/2

Length typeExtra Long

Material applicationStainless Steel; High-Temperature Alloy; Hardened Steel

Material removal typeFinishing

Mill diameter in3/32

Mill diameter tolerance-0.0020/0.0000 in

Number of flutes5

Overall length in2-1/2

Overall length tolerance-0.0620/0.0620 in

PitchVariable

Primary workpiece materialStainless Steel; Superalloys & Titanium; Hard Material

Secondary workpiece materialSteel; Cast Iron

Shank diameter in1/4

Shank diameter toleranceh6

Shank typeStraight-Cylindrical

Single or double endSingle

Tir maximum0.0005

Variable helixNo

Variable indexYes
